<% Title = "Bit-Tradition-Rugged Portable Computer- 8 x PXI free Slots-AC/DC wide range PC-Battery Backup-IP54 Protected-MIL-810G-MIL-STD-410F" Description = "The Bit Tradition RPC is a sealed rugged portable with 8 x PXI slots computer that has been designed for use in the toughest environments." Keywords = "rugged portable computer, luchbox computer, PXI free slots, rugged lunchbox PC, MILPAC, FlexPAC, FieldPAC, Dolch" Header = "bg-header-portable.jpg" BreadCrumbStr = "100#1#36#95" BreadCrumbCount = 4 %> <% GetProductHTMLTop "topitem_Products", "dropMenu_Products", "dropMenu_Products_Rugged_Portable_PCs", "", "", "Rugged_Portable_PC", "Bit_RPC_1500_PXI", "" GenerateBreadCrumb BreadCrumbStr, BreadCrumbCount GenerateProductFeatures "8 Slot PXI backplane incl. timer device#Easy Access to PXI Slot Cards#381mm / 15” diagonal viewing area #1400 x 1050 pxs SXGA+ screen resolution#16M Colors#VGA or DVI Interface support#Keyboard with backlight and integrated mouse device#Wide Range DC Supply (10-32V)#Wide Range AC Supply Input up to 400 Hz#2 Years Warranty", "RPC-1500-PXI R01.00 20.02.2011.pdf", Title, "dropMenu_Products", "dropMenu_Products_Rugged_Portable_PCs", "Rugged_Portable_PC", "Bit_RPC_1500_PXI" GenerateContentHeadline "Bit-RPC-1500-PXI", "" GeneratePictureSlider2 "rpc-1500-pxi/bit-rpc-1500-pxi.jpg#rpc-1500-pxi/01.jpg#rpc-1500-pxi/02.jpg#rpc-1500-pxi/03.jpg#rpc-1500-pxi/04.jpg#rpc-1500-pxi/05.jpg", "" GenerateProductMenu("") OpenProductInformationbox() GenerateOverviewText "

The Beltronic Bit-RPC-PXI is a completely sealed rugged portable computer has been designed for use in the toughest environments. It can be used where laptops and normal portables fail. This extra robust portable was developed to cope with the daily strains which factory tools are exposed to. eg., outdoor use, service and repair, flightpath system analysis, geophysical exploration, and naval and military use.


To withstand use outdoors the Bit- RPC is made from corrosion resistant aluminium which shields the internal parts from shocks to 30g. Furthermore the computer is weatherproof and certified to NEMA12/IP65. Consequently there is no problem using it outdoors where exposure to rain, dust or snow can be expected to be part of the normal day.


The folding keyboard protects the 15"" SXGA display. The high resolution of 1400 x 1050 ensures the readability even from bigger distances and in harsh environments. The Bit -RPC can be expanded by use of up to 7 x PXI slots. The Bit -RPC can be used anywhere in the world; the power supply can work with AC voltages from 90 to 265 at 50-60Hz or, using a cigarette lighter cable in the car, with DC voltages from 12-32. The built-in battery allows up to 30 min independent working.

", "", "" GenerateSpecificationText "Computer System#Backplane System#CPU Card##Optical Drive##Size#Resolution#Viewing Area#Aspect Ratio#Pixel Size#Viewing Angle#Backlight##USB#Video#PXI Card Interfaces##Supply Voltage DC#Supply Voltage AC#UPS (as Option)#UPS Monitoring##Material#Coating / Painting#Outside Dimensions#TFT Protection#Special Features#Weight##Temperature#Humidity#Operating Altitude#Vibration#Shock#IP Protection##CE", " #PXI 8 Slot 3U Backplane with integrated Timer Unit#To be supplied or assembled by customer# # Slimline SATA DVD Writer with Tray behind Service Door (with SATA to USB Adapter)# #381mm / 15,0” Industrial Grade TFT#1400 x 1050 pxs native SXGA+ resolution with 16M colours#381mm diagonal active view area (304.1mm x 228.1mm) (~15.0”)#4:3 aspect ratio#0,2175 mm pixel pitch#-40° ~ 40° typ. (H), typ. -15° ~ 30° (V)#200 cd/m² backlight with CCFL tube# #Integrated USB 2.0 Hub to connect Keyboard, Mouse, UPS and Optical Drive to CPU Card#VGA or DVI Support to be connected to CPU Card#Depending from Customer Configuration
All slot are easily accessible from top cover, which can be removed without tool# #10V-32V DC input on IP65 Round Connector#90V-240V with 45Hz-400Hz on IP65 Round Connector#Integrated UPS with Battery for approx. 10~15min. Runtime as Option#Monitoring with Serial Interface (COM-USB Adapter) with legacy driver in Windows XP pro# #Precision milled aluminum enclosure#Surtec 650 surface treatment, Light Grey powder coating#(H)335mm x (W)460mm x (D)240mm outside dimension over all#Hardened non-reflecting protection glass#Optical Drive behind Top Cover#Approx. 14 kg (without customer cards)# #0°C – 50°C Operating
-20°C – 60°C Storage#95% rh non condensating#10kft Operating
15kft Storage#1.5g 10-200 Hz, all 3 axis#50g 18ms, all 3 axis#IP22 (DIN EN 60259 / IEC 529) for main chassis
IP65 (DIN EN 60259 / IEC 529) for keyboard and integrated mouse device# #DIN EN 55022: 1998-04 Class A
DIN EN 55024: 2003-10 (DIN EN 61000-4-2: 2001-12, DIN EN 61000-4-3: 2001-12,
DIN EN 61000-4-4: 2002-07, DIN EN 61000-4-5: 2001-12, DIN EN 61000-4-6: 2001-12,
DIN EN 61000-4-8: 2001-12, DIN EN 61000-4-11: 2001-12)
DIN EN 61000-3-2: 2001-12
DIN EN 61000-3-3: 2002-05
DIN EN 60950/A11:1997", "" GenerateOptionalAccessoires "", "" GenerateVideos "", "" CloseProductInformationbox() GetHTMLButton() %>
